Arburg 420S ALLROUNDER 1000-350 injection moulding machine

Show in original language

This Arburg 420S ALLROUNDER 1000-350 injection moulding machine was manufactured in 2001. It is operated through a SELOGICA control unit. This machine has a clamping force of 1000 kN. The machine is in very good condition and still at the production. It is ready for tests.

Overview

brand: Arburg
year: 2001
MODEL: 420S ALLROUNDER 1000-350
application type: Injection Moulding
Location: Poland
machine type: Hydraulic Injection Moulding Machine

Technical Information - Arburg 420S ALLROUNDER 1000-350

General Data

Measurements width: 4400 mm
Measurements depth: 1700 mm
Measurements height: 2000 mm
Machine weight: 5100 kg

Injection Unit

Screw diameter: 35 mm
Shot weight: 127 g
Stroke volume: 139 cm3 CM³

Clamping unit

Clamping force: 1000 kN

Media

Main electronic connection: 3 X 400V / 50HZ

Additional Information

Machine Benefits

Technical Machine Benefits

Very good condition and still at the production.
It is ready for tests.
Heaters: 9. 4 kw
Pump motor: 22 kw
Hydraulic ejector
Pressure on material: 2500 bar
Distance between bars: 420 x 420 mm

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
