➤ Used Arburg Allrounder 470 S 1300-350 (2004) For Sale

Show in original language

This Arburg Allrounder 470 S 1300-350 was manufactured in 2004. It is a hydraulic injection moulding machine, ideal for precision plastic processing. Consider the opportunity to buy this Arburg Allrounder 470 S 1300-350 hydraulic injection moulding machine. Contact us for more information.

Overview

brand: Arburg
year: 2004
MODEL: Allrounder 470 S 1300-350 (2004)
application type: Injection Moulding
Location: Germany
machine type: Hydraulic Injection Moulding Machine

Technical Information - Arburg Allrounder 470 S 1300-350 (2004)

General Data

Measurements width: 2600 mm
Measurements depth: 5100 mm

Injection Unit

Screw diameter: 35 mm
Stroke volume: 139 ccm CM³
Injection pressure: 2500 bar

Clamping unit

Clamping force: 130 kN
Distance between bars: 470 mm

Additional equipment

- Robot: Wittmann W621-1618
- 2x Temperature Control Units: HB-Therm Series 4
- 1x Temperature Control Unit: HB-Therm Thermo 5
- Plus Peripherals

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Tonnage: 130 tons
- - Number of hydraulic core pulls (moving side): 1
- - Valve gate: 1 / hk control points: 6 (3)
- - Center ring diameter: 125 mm
- - Coupling diameter: 32 mm
- - Maximum opening: 579 mm / maximum plate distance: 852 mm / maximum ejector length: 175 mm
- - Language options: german, english
- - Robot robot vacuum circles nr. : 8
- - Robot gripper circles nr. : 2
- - Travel paths: x-550, y-1200, and z-1500 mm.

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
