CIDAN FORMA 30

Photo Gallery

CIDAN - FORMA 30PL-BEN-CID-2019-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Sheet Metal Machinery
➤ Used CIDAN FORMA 30 For Sale | gindumac.com

Show in original language

This CIDAN FORMA 30 die bending machine was manufactured in 2019. It features a working length of 3100 mm, a maximum sheet thickness for aluminum at 4.5 mm, and is equipped with ProLink CNC control. The machine includes a rotating upper beam type COMB with a quick-clamping tool system and an adjustable bending beam speed via inverter. If you are looking to get high-quality bending capabilities, consider the CIDAN FORMA 30 machine we have for sale. Contact us for more information.

Overview

brand: CIDAN
year: 2019
MODEL: FORMA 30
production hours: 5568
application type: Bending
Location: Poland
machine type: Die Bending Machine

Technical Information - CIDAN FORMA 30

General Data

Measurements width: 1800 MM
Measurements depth: 4100 MM
Measurements height: 1845 MM
Machine weight: 4750 KG

Main drive

Main motor power: 7.9 KW

Max Material thickness

Stainless steel: 1.9 mm
Aluminum: 4.5 mm

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Voltage: 3x400v pe+n
- - Max sheet thickness (rm=400 n/mm²): 3. 0 mm
- - Opening: 195 mm
- - Cnc control: prolink
Qualitative Machine Benefits:
- - Driven backgauge
- - Rotating upper beam type comb with quick-clamping tool system
- - Adjustable bending beam speed via inverter
- - Multifold divided tools for the lower bending beam

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
