DTM CD 320 universal cycle controlled Lathe

Show in original language

This DTM CD 320 universal cycle controlled Lathe machine was made in the year 2000 in Germany and has 4730 operating hours. It is equipped with Heidenhain MANUALplus 4110 control unit. The machine has a diameter over bed of 320mm, a diameter over cross slide of 150mm, and includes a Sauter - disk revolver with electric drive for 8 tools (no driven tools).

Overview

brand: DTM
year: 2000
MODEL: CD 320
production hours: 4730
application type: Turning
Location: Germany
machine type: Horizontal Turning Machine
availability: Sold
control unit brand: HEIDENHAIN

Technical Information - DTM CD 320

Control Unit

Model: MANUALplus 4110
Brand: HEIDENHAIN

Additional equipment

- Sauter - disk revolver with electric drive for 8 tools (no driven tools)
- LTA - Air Filter

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Diameter over bed: 320 mm
- - Diameter over cross slide: 150 mm
- - Cross slide: 200 mm
- - Peak width: 750 mm (evtl. 1000 mm but need to confirm)
- - Spindle head din 55027 size gr. 5 / hole 50mm
- - Main spindel: digital ac motor 40/60/100% ed kw 11/9/8
- - Gear stages: 3

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
