➤ Used IMA BIMA 310 120/300 - For Sale | gindumac.com

Show in original language

This 3-axis IMA BIMA 310 120/300 CNC Wood Machining Centre was manufactured in 1999. If you are looking to get high-quality woodworking capabilities, consider the IMA BIMA 310 120/300 machine we have for sale. Contact us for more information.

Overview

brand: IMA
year: 1999
MODEL: BIMA 310 120/300
application type: CNC Wood Machining
Location: Switzerland
machine type: CNC Wood Machining Centre
control unit brand: SIEMENS

Technical Information - IMA BIMA 310 120/300

General Data

Machine weight: 5000 kg

Control Unit

Brand: SIEMENS

Main drive

Spindle speed range: 6000 - 9000 rpm 1/MIN
Spindle motor power: 12 kW
Number of axis: 3

Movement

X-AXIS Movement: 3000 mm
X-AXIS Rapid traverse: 50 m/min
Y-AXIS Movement: 1000 mm
Y-AXIS Rapid traverse: 50 m/min
Z-AXIS Rapid traverse: 25 m/min

Tools

Max weight: 6 kg
Max tool diameter: 150 mm
Type of tool holder: HSK F63

Additional Information

Additional equipment

1 vertical drilling unit in Y Direction
1 vertical drilling unit in X Direction
1 main spindle with programmable direction of rotation
1 centrally integrated CNC axis rotating 360 degrees
1 adapter unit saw, fixed at 90 degrees
Saw blade diameter: 200 mm
1 adapter unit horizontal drilling and milling head (cross head)
1 adapter unit horizontal milling cutter (face milling)
2x adapter units for hinge drilling
Includes 1 new Siemens vacuum pump + numerous accessories

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
