➤ Used JOBS FRAZER Milling Machine For Sale | gindumac.com

Show in original language

This 4-axis JOBS FRAZER cnc milling machine was manufactured in 2017. It features a large fixed table of 3100x1000 mm and high-speed axes capable of up to 35 m/min, ensuring efficient machining. The machine includes a Heidenhain iTNC 530 HSCI CNC for precise control and a 24-position disc tool magazine. If you are looking to get high-quality milling capabilities, consider the JOBS FRAZER machine we have for sale. Contact us for more information.

Overview

brand: JOBS
year: 2017
MODEL: FRAZER
application type: Milling
Location: Italy
machine type: Gantry Milling Machine
control unit brand: HEIDENHAIN

Technical Information - JOBS FRAZER

Control Unit

Brand: HEIDENHAIN
Model: ITNC 530

Main drive

Number of axis: 4

Movement

X-AXIS Movement: 3000 MM
Y-AXIS Movement: 1500 MM
Z-AXIS Movement: 1100 MM

Additional Information

Additional equipment

Direct hydraulic balancing system (double cylinder)
Workpiece : Fixed table: 3100x1000 mm
Table : External low-pressure spindle cooling system
Disc tool magazine with 24 ISO50 positions, with tool exchanger arm, complete with support and management software located at the end of X-axis travel
Hydraulic system, power supply, and wiring / 6000 W cooling unit / Hydraulic and electric cabinets (Rittal) on the ground
Work area lighting; Machine and spindle hour counters / External operator station on the ground – mobile operator panel / C-axis with torque motor
2 longitudinal screw chip conveyors + 1 transversal belt conveyor / Safety fences including panels and sliding steel door with Lexan window, compliant with CE safety standards. Upper cover included.
Dividing wall and software setup for pendulum machining / Renishaw RMP60 digital probe
BLUM fixed laser presetter station, including Blum measurement cycles + zeroing sphere
Voltage: 400 Vac / Frequency: 50 Hz

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
