Front view of Peddinghaus Avenger MDL1000B machine
Front view of Peddinghaus Avenger MDL1000B machine

Thank you for your visit

This machine was recently sold.

Browse similar machines

Peddinghaus - Avenger MDL1000BIE-DRI-PED-2005-00001

Sold

Do you have further questions? Contact us.

sales contact

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

whatsapp
Click to chat on WhatsApp
Show in original language

This Peddinghaus Avenger MDL1000B Drilling machine was manufactured in the year 2005 in the United States. It is equipped with a Siemens Sinumerik 840D control unit. The machine has a table of 1830 x 1000 mm, and includes a Rush 250A Drill Grinder and a Selection of Drills as additional equipment.

Overview

  • brand: Peddinghaus
  • year: 2005
  • MODEL: Avenger MDL1000B
  • application type: Other Machine Tools
  • Location: Ireland
  • machine type: Drilling Machine (Metal)
  • control unit brand: SIEMENS

Technical Information - Peddinghaus Avenger MDL1000B

General Data

  • Measurements width: 2050 mm
  • Measurements depth: 3500 mm
  • Measurements height: 2560 mm

Control Unit

  • Model: Sinumerik 840D
  • CNC main language: English
  • Brand: SIEMENS

Movement

  • X-AXIS Movement: 1830 mm
  • Y-AXIS Movement: 330 mm

Workpiece

  • Workpiece x: 1830 mm
  • Workpiece y: 1000 mm

Table

  • Outer length: 1830 mm
  • Outer width: 1000 mm

Tools

  • Max tool diameter: 50 mm

Media

  • Main electronic connection: 400 V
  • Power consumption: 14,9 kW

    Additional equipment

    • - Rush 250A Drill Grinder
    • - Selection of Drills

    Additional Information

      Machine history

      • End product: Structural steel beams
      • Industries: Structural steel industry

      Machine Benefits

      • Technical Machine Benefits:
        • - New machine control in 2017
        • - Includes a rush 250a drill grinder worth €6,000
        • - Table: 60 ft
        • - Average output: 200 to 400 holes per hour
        • - Max beam size: 60ft x 40" (18. 3m x 1000mm)
        • - Max beam weight: 730lbs/ft (1088kg/m)
        • - Min drill diameter: 1/4" (6. 5mm)
        • - Max drill diameter: 2" (50mm)
        • - Max thickness: up to 10" (250mm)
        • - Max speed x-axis: 120 ft/min (37m/min. )
      • Qualitative Machine Benefits:
        • - Max speed y-axis: 120 ft/min (37m/min. )
        • - Spindle power: 13 3/4hp (10kw)
        • - Drilling feed rate: 2" – 10" per min (50-254mm/min) infinitely variable

    *There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
