Front view of STUDER S30 lean Pro machine

Thank you for your visit

This machine was recently sold. Take a look at similar options or get in touch with us directly.

Browse all similar machines

Browse similar machines

STUDER S30 lean Pro

Photo Gallery

STUDER - S30 lean ProIE-GRI-STU-2001-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
➤ Pre-Owned STUDER S30 lean PRO Grinding Machine

Show in original language

This STUDER S30 lean Pro Grinding Machine was made in the year 2001 in Switzerland. It has been working for 42769 hours and is operated through a Fanuc Series 16-T control unit. This machine can work with a spindle speed up to 20000 rpm. It has been well maintained.

Overview

brand: STUDER
year: 2001
MODEL: S30 lean Pro
production hours: 42769
application type: Grinding
Location: Ireland
machine type: Cylindrical Grinding Machine
availability: Sold
control unit brand: FANUC

Technical Information - STUDER S30 lean Pro

General Data

Measurements width: 3710 mm
Measurements depth: 2160 mm
Measurements height: 2290 mm
Machine weight: 6000 kg

Control Unit

Model: Series 16-T
CNC main language: English
CNC language customizable: Yes
Brand: FANUC

Main drive

Spindle speed range: 2110 1/MIN

Movement

X-AXIS Movement: 275 mm
Z-AXIS Movement: 1050 mm
B-AXIS Movement: *-15 to 195 Degrees MM

Workpiece

Workpiece weight: 130 kg

Tools

Max tool diameter: 500 mm

Media

Main electronic connection: 400 V

Additional Information

Machine history

Material type: Steel
End product: Pump components

Machine Benefits

Technical Machine Benefits:
- - C axis as standard
- - Id/od cnc grinder
- - No id spindle on machine
Qualitative Machine Benefits:
- - Well maintained machine

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
