➤ Used AMADA EMZ3612M2 For Sale | gindumac.com

Show in original language

This 4-axis AMADA EMZ3612M2 was manufactured in 2016, featuring a high-speed servo-electric turret punch press with twin AC servo direct drive. It boasts a 33-ton press capacity and an AMNC-F / AMNC-4ie CNC system for enhanced control. The machine handles sheet formats up to 3050x1525 mm and includes a "King" turret with up to 58 stations. Energy efficiency is optimized with AC servo drives. If you are looking to get high-quality punching capabilities consider the AMADA EMZ3612M2 machine we have for sale. Contact us for more information.

Overview

brand: AMADA
year: 2016
MODEL: EMZ3612M2
application type: Punching
Location: Hungary
machine type: Turret Punch Press

Technical Information - AMADA EMZ3612M2

General Data

Measurements width: 6212 mm
Measurements depth: 5436 mm
Measurements height: 2342 mm
Machine weight: 21500 kg

Main drive

Number of axis: 4

Movement

X-AXIS Movement: 3050 mm
Y-AXIS Movement: 1525 mm
Z-AXIS Movement: 37 mm

Turret

Number of turrets: 1

Additional equipment

- Air-blow oil-mist lubrication
- Slug-vacuum system
- Digital tool ID / barcode system
- Integrated tapping: inch/metric taps (M2.5–M8)
- Marking & deburring tools: on-board marking and deburring options

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Type: high-speed servo-electric turret punch press with twin ac servo direct drive
- - Press capacity: 33 tons (300 kn)
- - Maximum sheet format (without repositioning): 3050 × 1525 mm
- - Turret type: “king” turret – triple-track, available in 55-station multi-purpose or 58-station version, with 4 auto-index stations including tapping units
- - Turret rotation speed: up to 30 rpm
- - Feed clearance: 25 mm between turret plates
- - Max sheet thickness: 4. 5 mm
- - Positioning speed (x/y): 100 m/min / 80 m/min

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
