DECKEL MAHO - DMU 50 TDE-MIL-DEC-1999-00008

Additional Information

Machine Benefits

• Technical Machine Benefits:
  • - Max. Torque 57 / 82 nm
  • - Swivelling rotary table: table diameter 700 x 500 mm swivelling man.
  • - Torque 57 / 82 nm tool holder ( sk 40 ) swivelling rotary table: table diameter 700 x 500 mm swivelling man
  • - B: 105° (-10°/+95) °
  • - Rotatable man. 360 ° max.
  • - No. Of t-slots 7
  • - T-slots: distance 63 mm
  • - T-slots - width 14h7 mm
  • - Centre bore 30h6 mm
  • - Tool changer: no. Of tool positions 16 pos.
• Qualitative Machine Benefits:
  • - Max. Tool length 290 mm
  • - Max. Tool weight 6. 0 kg
  • - Max. Total weight 50 kg
  • - Total weight 50 kg
  • - Feed rates: feed speed max. 10,000 mm/min
  • - Rapid traverse 12 m/min
  • - Feed unit 0. 01 mm
  • - Total power requirement 17 kw
  • - Documentation b-axis c-axis nc swivelling rotary table manual / manual tool changer 16 pos. Electr. Handwheel coolant device
