HAAS - VF-4SSCZ-MIL-HAA-2018-00001

Additional equipment

• - linear rolling prestressed axle guide
• - 15" LCD color monitor
• - electronic micro scroll wheel
• - module for quick detection of power failure
• - 2 hand guns for air and liquid cleaning
• - hanging tool shelf and notebook holder
• - feet for setting up the machine
• - WIP-S Renishaw probes
• - 32GB extended memory
• - TSC ready

Additional Information

Machine Benefits

• Technical Machine Benefits:
  • - 3-axis version
  • - Working tracks x,y. Z = 1,270 x 508 x 635 mm
  • - Dimensions of the work table 1321 x 457 mm
  • - Number/dimension/spacing t-slot = 5 / 16mm / 80 mm
  • - Distance of the entire drive / surface of the table = 107-742 mm
  • - Iso40 / din69871/a drive type
  • - Max. Drive speed 12,000 rpm // max. Output 22. 4 kw, inline direkt drive drive // max. Spindle torque 122 nm
  • - 208 liter coolant tank with pump // cooling block with adjustable nozzles around the fan
  • - Electric connected 3x400v/50hz, 28kva
  • - Central automatic grease lubrication (spindle oil) // operating memory 1 gb // usb and ethernet communication interfaces
• Qualitative Machine Benefits:
  • - Hours: run time: 9309h, feed cutting time: 2113h > excellent condition!
  • - Cnc control system haas in destination, compatible with fanuc
  • - Solid cast iron construction
  • - Temperature stabilization of the spindle , direct threading
  • - Lighting of the working area of the machine
  • - Ce version of the machine
  • - High speed machining

Payment Terms

• Payment in advance

• Asset Financing
