YCM NH 500A

Photo Gallery

YCM - NH 500ASI-MIL-YCM-2021-00001

Sold

Do you have further questions? Contact us.

Sergi Guardia

+49 162 4027635

s.guardia@gindumac.com

Click to chat on WhatsApp

GINDUMAC
Products
Machine Tools
YCM NH 500A Horizontal Machining center

Show in original language

This YCM NH 500A Horizontal Machining center was manufactured in the year 2021 in Taiwan. The machine has a spindle speed of 15000 rpm.

Overview

brand: YCM
year: 2021
MODEL: NH 500A
application type: Milling
Location: Slovenia
machine type: Horizontal Machining Centre
availability: Sold

Technical Information - YCM NH 500A

Main drive

Spindle speed range: 15000 1/MIN
Spindle motor power: 37 kW
Tool taper: BBT40

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Two pallets 500x500 with holes for workpiece clamping and hydraulic clamping (70 bar 2in/2out)
- - 70 bar coolant through the spindle
- - Magazine with 120 tools
- - Tool change: t to t 2 sec.
- - Rapid traverse (x/y/z): 60 m/min
- - Accelerations: 1g
- - Table indexing (b-axis) 0. 001°
- - Max. Table rotation: 22. 2 rpm
- - Linear scales in all axes.

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
